Motorola System V/88 Release 4.0 Version 4.2


Features

New Feature Description
MVME197 support supports the MVME197DP board in addition to the MVME197LE board.
ISO 9660 CD-ROM File System supports the ISO 9660 CD-ROM file system.
System tuning utilites three new tuning utilities: lsattr,lsdev and chdev. buildsys command added

Board Revision Levels


Board Description Max count Min Revision Part Number
MVME181 1 MC881000 CPU, 2 MC88200 CMMU, 8MB DRAM 1 01C 01-W2336C
M8120 20MHz or 25MHz 1 88100 CPU
1 or 2 MC88200 CMMU,single board computer
1 01D through 06D 01-W3817B
M8220 33MHz, 2 CMMU, 3-slot assembly 1 04F 01-W2242D
M8420 33MHz, 2 CMMU, 6-slot assembly 1 02F 01-W2242D
MVME187
MVME187A
MVME187B
MVME187C
25MHz 1 MC88100 CPU,2 MC88200 CMMU
4MB,8MB,16MB or 32MB Parity Memory
1 01F
02F
03F
04F
01-W3689B
MVME187-01
MVME187-02
MVME187-03
MVME187-04
25MHz 1 MC88100 CPU,2 MC88200 CMMU
4MB,8MB,16MB or 32MB Parity Memory
1 01A
02A
03A
04A
01-W3827B
MVME187-01A
MVME187-02A
MVME187-03A
MVME187-04A
25MHz 1 MC88100 CPU,2 MC88200 CMMU
4MB,8MB,16MB or 32MB Parity Memory
1 01B
02B
03B
04B
01-W3827B
MVME187-23
MVME187-24
25MHz 1 MC88100 CPU,2 XC88200 CMMU
16MB or 32MB Parity Memory
1 23A
24A
01-W3827B
MVME187-01A
MVME187-02A
MVME187-03A
MVME187-04A
33MHz 1 MC88100 CPU,2 MC88200 CMMU
4MB,8MB,16MB,32MB,64MB or 128MB ECC Memory
1 31A
32
33A
34A
01-W3827B
MVME187-031A
MVME187-032A
MVME187-033A
MVME187-034A
MVME187-035A
MVME187-036A
33MHz 1 MC88100 CPU,2 MC88200 CMMU
4MB,8MB,16MB,32MB,64MB or 128MB ECC Memory
1 31D
32D
33D
34D
35D
36D
01-W3827B
MVME188 MVME188 Family:
188 Main Logic Board 20MHz
188 Main Logic Board 25Mhz
188A Main Logic Board 20MHz
188A Main Logic Board 25MHz
188 System Controller Board
188A System Controller Board
HYPERmodules:
20MHz HYPERmodule 1 MC88100 CPU
4 MC88200 CMUU (1P64)
25MHz HYPERmodule 1 MC88100 CPU
4 MC88200 CMUU (1P64)
20MHz HYPERmodule 2 MC88100 CPU
4 MC88200 CMUU (2P64)
25MHz HYPERmodule 2 MC88100 CPU
4 MC88200 CMUU (2P64)
25MHz HYPERmodule 2 MC88100 CPU
4 XC88200 CMUU (2P256)
20MHz HYPERmodule 1 MC88100 CPU
8 MC88200 CMUU (1P128)
25MHz HYPERmodule 1 MC88100 CPU
8 MC88200 CMUU (1P128)
20MHz HYPERmodule 2 MC88100 CPU
8 MC88200 CMUU (2P128)
25MHz HYPERmodule 2 MC88100 CPU
8 MC88200 CMUU (2P128)
25MHz HYPERmodule 2 MC88100 CPU
8 XC88200 CMUU (2P512)
20MHz HYPERmodule 4 MC88100 CPU
8 MC88200 CMUU (4P128)
25MHz HYPERmodule 4 MC88100 CPU
8 MC88200 CMUU (4P128)
25MHz HYPERmodule 4 MC88100 CPU
8 XC88200 CMUU (4P512)
25MHz HYPERmodule 2 MC88100 CPU
4 MC88200 CMUU (2P256)
Memory:
188 16MB DRAM Memory Board
188 64MB DRAM Memory Board
188A 16MB DRAM Memory Board
188A 64MB DRAM Memory Board
188A 128MB DRAM Memory Board

1
1
1
1
1
1

1

1

1

1

1

1

1

1

1

1

1

1

1

1


4
4
4
4
4

03E
02D
01A
02A
02G
01E

01C

02B

01C

02A

04A

01C

02C

01C

02C

04A

01C

02C

04A

04A


02C
01C
02B
01B
01A

01-W3546B
01-W3546B
01-W3731B
01-W3731B
01-W3547B
01-W3730B

01-W3576B

01-W3576B

01-W3545B

01-W3545B

01-W3545B

01-W3554B

01-W3554B

01-W3556B

01-W3556B

01-W3556B

01-W3557B

01-W3557B

01-W3557B

01-W3545B


01-W3646B
01-W3646B
01-W3729B
01-W3729B
01-W3782B
MVME197-001
MVME197-002
88110 CPU, LE, 32MB or 64MB DRAM, 50MHz 1 03L
04L
01-W3869B
MVME197-003
MVME197-004
88110 CPU, LE, 32MB or 64MB DRAM, 40MHz 1 01M
02M
01-W3869B
MVME197-101
MVME197-201
88110 CPU, SP or DP, 128MB DRAM, 50MHz 1 04F*,04G
03F*,03G
01-W3815B
MVME297FC
MVME297FD
32MB or 64MB Parity Memory for MVME197/Series 900 2 01E
02E
01-W3918B
MVME297FE
MVME297FF
128MB or 256MB Parity Memory for MVME197/Series 900 2 01J
02J
01-W3892B
MVME224-1 4MB or 8MB Parity Memory(MVME181 only) 2 01E
02E
01-W3500B
MVME224A-1 4MB,8MB or 16MB Parity Memory(MVME181 only) 2 01E
02E
03E
01-W3588B
MVME236-1
MVME236-2
4MB or 8MB Parity Memory(MVME181 only) 4 01A
02A
03A
01-W3561B
MVME259FB
MVME259FC
16MB or 32MB ECC First Mezzanine 4 03A
04A
01-W3914B
MVME259FD
MVME259FE
64MB or 128MB ECC First Mezzanine 4 01A
02A
01-W3828B
MVME260FB
MVME260FC
16MB or 32MB Second Mezzanine 4 07A
08A
01-W3800B
MVME260FD
MVME260FE
64MB or 128MB Second Mezzanine 4 03A
04A
01-W3828B
MVME288-064
MVME288-016
64MB or 16MB Parity Memory 4 01B
02B
01-W3729B
MVME288
MVME288DF
64MB or 16MB Parity Memory (extra) 4 01B
02B
01-W3646B
MVME288EC-032
MVME288FE128
32MB or 128MB ECC Memory Board 4 01B
01A
01-W3727B
MVME328-1
MVME328-2
SCSI Single-Channel Controller 6 01G
02G
01-W2625C
MVME328S-1
MVME328S-2
MVME328S-4
MVME328S-5
SCSI Single-Channel Controller 6 01C
02C
03C
04C
01-W2220D
MVME328FXTP-1
MVME328FXTP-2
SCSI Single-Channel Controller 6 01A
02A
01-W2513D
MVME332XT 8 Serial Port / 1 Parallel Port
Asynchronous Communications Controller
8 02C 01-W3475B
MVME332FXTP 8 Serial Port / 1 Parallel Port
Asynchronous Communications Controller
8 02B 01-W3822B
MVME337-1 32 Serial Port Asynchronous Communications Controller 4 13F 01-W3440B
MVSB741 16Channel Asynchronous Extensible VSB (EVSB) Module 4 per
MVME337
01B 01-W3638B
MVME338
MVME338FP
Systech UnPlug 8 01B 01-W2840C
MVME339
MVME339FP
Systech Etherplex 4 01A 01-W2476D
MVME374 Intelligent Ethernet LAN Controller 2 01K 01-W3517B
MVME374-1 Intelligent Ethernet LAN Controller 2 01A 01-W3790B
MVME376
MVME376FP
Hawk Ethernet Controller 4 01A 01-W2046D
MVME385 FDDI Controller 2 01B 01-W2047D


Peripheral Devices

Disk drives

Model Number Descrption Vendor Model
MVME864A 180MB Fujitsu 2614 Disk Drive M2614ESA
MVME865 330MB Fujitsu 2622 Disk Drive M2622SA
MVME866 520MB Fujitsu 2624 Disk Drive M2624SA
MVME867 1GB Seaagate Disk Drive ST11200N
MVME868 2GB Seaagate Disk Drive ST12400N
MVME874 150MB SCSI Winchester Disk Drive (WREN III) 94161-15
MVME875 300MB SCSI Winchester Disk Drive (WREN IV) 94171-30
MVME876 600MB SCSI Winchester Disk Drive (WREN V) 94181-70
MVME877 1.2GB SCSI Winchester Disk Drive (WREN VII) 94601-12
MVME881 655KB/1.2MB 5.25-inch Teac Floppy SCSI Disk Drive and Controller FD55-GFR
MVME884 655KB/2.9MB 3.5-inch Teac Floppy SCSI Disk Drive and Controller FD235-JS
MVME888 Toshiba CD-ROM Drive 3201B


Tape drives

Model Number Descrption Vendor Model
MVME853 150MB Archive QIC Tape Drive with embedded SCSI 2150S
MVME854 525MB Archive QIC Tape Drive with embedded SCSI 2525S
MVME855 155MB TEAC 3.5 inch Cartridge Drive MT-2ST/N
MVME856 2.3GB SCSI Cartridge Tape Drive (Exabyte) EXB-8200
MVME857 Digital Audio Tape (DAT) Tape Drive 4322NP
MVME858-1 9-Track 1600/6250 BPI SCSI 1/2-inch Tape Drive 6250
MVME859-1 9-Track M4 Dual Density Tape Drive 9905
MVME859-2 9-Track M4 Quad Density Tape Drive 9914


No boot support

Model Number Descrption
MVME859-1 9-Track M4 Dual Density Tape Drive
MVME859-2 9-Track M4 Quad Density Tape Drive
MVME881 9-Track 1600/6250 BPI SCSI 5.25-inch Tape Drive
MVME884 9-Track 1600/6250 BPI SCSI 3.5-inch Tape Drive
MVME856 2.3GB SCSI Cartridge Tape Drive (Exabyte)


Custom firmware

Model Number Descrption
MVME864A 180MB Fujitsu 2614 Disk Drive
MVME866 520MB Fujitsu 2624 Disk Drive
MVME856 2/3GB SCSI Cartridge Tape Drive (Exabyte)
